BUCHER SA MINI POWER PACKS

Bucher

Hydraulic Power Packs, Series UP...

PP3

These units feature a high degree of accuracy and have a wide application range. Bucher Hydraulics power packs are designed with an integrated modular system of valves for the various functions.

This highlights the equipment's compact nature, the foundation of its high performance level.

The basic components of the power pack are:

  • a manifold block with cavities for various types of valves
  • a very quiet, high efficiency gear pump
  • an electric motor (DC or AC)
  • a reservoir (plastic or steel)
  • several optional accessories

Advantages:

  • Compact and modular construction. limited number of components, quick and easy assembly
  • Maxiumum flexibility - numerous different circuits can be built from just the few basic versions
  • Valve cavities conform to international standards
  • Optimisation of motor-pump unit produce increased efficieny and low operating noise level

Technical data:



UP50

UP100

UP110

Displacement

cm³/rev

0.25 - 2.3

1.2 - 10.0

1.2 - 10.0

P2 intermittent pressure up to:

bar

230

230

230

12 VDC electric motor power*

kW

0.35 - 2.0

0.8 - 2.0

0.8 - 2.0

24 VDC electric motor power*

kW

0.4 - 2.5

1.2 - 3.0

1.2 - 3.0

48 VDC electric motor power*

kW

2.0

2.0

-

220V/380V AC elec. motor power

kW

0.12 - 0.75

0.25 - 4.0

0.25 - 4.0

Tank capacity

Liter

0.5 - 4.0

1.5 - 18.0

1.5 - 18.0

* The above motors are normally rated for intermittent operation

Electric motors for continuous rating are also available on request.

Models:

  • Unidirectional
  • Reversible (UP50 only)
  • Manual/solenoid control, 2 way / 3 way / 4 way
  • Modular blocks for Cetop2 - 3 solenoid vavles
  • Emergency handpump
  • Customised manifolds to match client's specific requirements
